PL 35 Series
BOX WAY TYPE TURNING CENTER

The Special Design that Archieve High Rigidity!


Product Features

  • Radiator fan-like pin tube rib design dissipates heat generated by axis movements, maintaining minimal thermal expansion.
  • Low vibration & high rigidity are maintained by seperation the spindle motor & gear box from spindle.

Major Specifications

( ) : Big Bore [ ] : Option
DESCRIPTION PL 35 PL 35L PL 35M PL 35LM
Swing over the bedmm 600 600 680 680
Max. machining diameter×lengthmm 420 × 780 420 × 1,530 500 × 780 500 × 1,500
Max. machining bar sizemm 90 (117) 90 (117) 90 (117) 90 (117)
Chuck size inch 12[15] 12[15] 12[15] 12[15]
Spindle speed rpm 2,500 (2,000) 2,500 (2,000) 2,500 (2,000) 2,500 (2,000)
Spindle nose ASA A2-8 (A2-11) A2-8 (A2-11) A2-8 (A2-11) A2-8 (A2-11)
Spindle motor(cont./30min) kW 18.5/22 18.5/22 18.5/22 18.5/22
Rapid traverse(X/Z) m/min 12/15 12/15 20/24 20/24
Axis travel(X/Z)mm 240/855 240/1,605 280/825 280/1,575
Number of tool positionsea 10[12] 10[12] 12(BMT65) 12(BMT65)
Shank size for square toolmm 25 × 25 25 × 25 25 × 25 25 × 25
Shank size for boring barmm 50 50 50 50
Tailstock travelmm 130 130 130 130
Machine weightkgf 8,000 9,000 8,300 9,300
Required floor space(L×W)mm 3,620×1,845 4,990×1,845 3,620×1,897 4,990×1,897
Controller Fanuc Oi-TD
